Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
65 | 165/65R13 | 77 | T | 5J | 170 | 544 | 250 | 412 |
70 | 165/70R13 | 79 | T | 5J | 170 | 562 | 250 | 437 |
175/70R13 | 82 | T | 5J | 177 | 576 | 250 | 475 | |
185/70R13 | 86 | T | 5.50B/51/2J | 189 | 590 | 250 | 530 | |
80 | 155/80R13 | 79 | T | 4 1/2J | 157 | 578 | 240 | 437 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
60 | 165/60R14 | 75 | H | 5J | 170 | 554 | 250 | 387 |
185/60R14 | 82 | H | 51/2J | 189 | 578 | 250 | 475 | |
65 | 155/65R14 | 75 | T | 4 1/2J/4.50B | 157 | 558 | 250 | 387 |
165/65R14 | 79 | T | 5J | 170 | 570 | 250 | 437 | |
175/65R14 | 82 | T | 5J | 177 | 584 | 250 | 475 | |
185/65R14 | 86 | H | 51/2J | 189 | 596 | 250 | 530 | |
70 | 165/70R14 | 85/XL | T | 5J | 170 | 588 | 290 | 515 |
175/70R14 | 84 | T | 5J | 177 | 602 | 250 | 500 | |
185/70R14 | 88 | H | 51/2J | 189 | 616 | 250 | 560 | |
T | 51/2J | 189 | 616 | 250 | 560 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
50 | 175/50R15 | 75 | H | 5 1/2J | 182 | 557 | 250 | 387 |
185/50R15 | 79 | V | 6J | 194 | 566 | 250 | 437 | |
195/50R15 | 82 | V | 6J | 201 | 577 | 250 | 475 | |
55 | 185/55R15 | 82 | V | 6J | 194 | 585 | 250 | 475 |
195/55R15 | 85 | H | 6J | 201 | 595 | 250 | 515 | |
V | 6J | 201 | 595 | 250 | 515 | |||
60 | 165/60R15 | 81/XL | H | 5J | 170 | 579 | 290 | 462 |
175/60R15 | 81 | H | 5J | 177 | 591 | 250 | 462 | |
185/60R15 | 88/XL | H | 51/2J | 189 | 603 | 290 | 560 | |
V | 51/2J | 189 | 603 | 290 | 560 | |||
195/60R15 | 88 | H | 6J | 201 | 615 | 250 | 560 | |
V | 6J | 201 | 615 | 250 | 560 | |||
205/60R15 | 91 | H | 6J | 209 | 627 | 250 | 615 | |
65 | 185/65R15 | 88 | H | 51/2J | 189 | 621 | 250 | 560 |
195/65R15 | 91 | H | 6J | 201 | 635 | 250 | 615 | |
V | 6J | 201 | 635 | 250 | 615 | |||
95/XL | H | 6J | 201 | 635 | 290 | 690 | ||
205/65R15 | 94 | V | 6J | 209 | 647 | 250 | 670 | |
215/65R15 | 100/XL | H | 61/2J | 221 | 661 | 290 | 800 | |
70 | 205/70R15 | 96 | H | 6J | 209 | 669 | 250 | 710 |
215/70R15 | 98 | H | 61/2J | 221 | 683 | 250 | 750 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
55 | 185/55R16 | 83 | V | 6J | 194 | 610 | 250 | 487 |
87/XL | V | 6J | 194 | 610 | 290 | 545 | ||
195/55R16 | 87 | V | 6J | 201 | 620 | 250 | 545 | |
91/XL | V | 6J | 201 | 620 | 290 | 615 | ||
205/55R16 | 91 | V | 61/2J | 214 | 632 | 250 | 615 | |
94/XL | V | 61/2J | 214 | 632 | 290 | 670 | ||
215/55R16 | 93 | V | 7J | 226 | 642 | 250 | 650 | |
97/XL | V | 7J | 226 | 642 | 290 | 730 | ||
215/55ZR16 | 97/XL | W | 7J | 226 | 642 | 290 | 730 | |
225/55R16 | 99/XL | V | 7J | 233 | 654 | 290 | 775 | |
60 | 195/60R16 | 89 | H | 6J | 201 | 640 | 250 | 580 |
205/60R16 | 92 | H | 6J | 209 | 652 | 250 | 630 | |
215/60R16 | 95 | H | 61/2J | 221 | 664 | 250 | 690 | |
225/60R16 | 98 | V | 61/2J | 228 | 676 | 250 | 750 | |
65 | 205/65R16 | 95 | V | 6J | 209 | 672 | 250 | 690 |
215/65R16 | 98 | V | 61/2J | 221 | 686 | 250 | 750 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
50 | 225/50R17 | 94 | V | 7J | 233 | 658 | 250 | 670 |
55 | 225/55R17 | 97 | V | 7J | 233 | 680 | 250 | 730 |
65 | 225/65R17 | 102 | H | 61/2J | 228 | 724 | 250 | 850 |
