Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
70 | 165/70R14C | 89/87 | R | 5J | 170 | 588 | 375 | 580 |
185R14C | 102/100 | Q | 51/2J | 188 | 650 | 450 | 850 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
70 | 195/70R15C | 104/102 | R | 6J | 201 | 655 | 450 | 900 |
215/70R15C | 109/107 | R | 61/2J | 221 | 683 | 450 | 1030 | |
225/70R15C | 112/110 | R | 61/2J | 228 | 697 | 450 | 1120 |
Aspect Rating | Size | Load Index | Speed Rating | Std.Rim | Section Width (mm) | Overall Diameter (mm) | Max Air Pressure (KPA) | Load Capacity (kg) |
65 | 195/65R16C | 104/102 | T | 6J | 201 | 660 | 475 | 900 |
205/65R16C | 107/105 | R | 6J | 209 | 672 | 475 | 975 | |
215/65R16C | 109/107 | R | 61/2J | 221 | 686 | 475 | 1030 | |
225/65R16C | 112/110 | R | 61/2J | 228 | 698 | 475 | 1120 | |
235/65R16C | 115/113 | R | 7J | 240 | 712 | 475 | 1215 | |
75 | 195/75R16C | 107/105 | T | 51/2J | 196 | 698 | 475 | 975 |
215/75R16C | 113/111 | R | 6J | 216 | 728 | 475 | 1150 | |
225/75R16C | 121/120 | R | 6J | 223 | 744 | 575 | 1450 |
